| Chipset |
nVIDIA nFORCE 3 250Gb |
| Processor |
AMD Socket 754 on board. |
| Front Side Bus |
800MHz Hyper Transport. |
| Memory |
- 2 x 184-pin DDR DIMM Sockets.
- Supporting unregistered non-ECC DDR 400/333 DRAM up to 2GB.
|
| Expansion Slots |
- 1 x AGP 8X/4X Slot.
- 5 x PCI Slots.
|
| On-Board EIDE |
- 2 x ATA133/100/66 IDE connectors supporting up to 4 IDE devices.
- 1 x ATA 133/100/66 IDE connector supporting up to 1 IDE devices by Promise
PDC20579. (For SL-K8AN2E-GR only)
|
| On-Board SATA |
- 2 x Serial ATA connectors supporting 2 Serial ATA HDDs.
(by NVIDIA nFORCE 3 250Gb)
- 2 x Serial ATA connectors supporting 2 Serial ATA HDDs.
(by Promise PDC20579) (For
SL-K8AN2E-GR only)
|
| |
|
| Integrated Super I/O |
- 1 x Floppy Port.
- 1 x PS/2 Mouse Port.
- 1 x PS/2 Keyboard Port.
- 1 x Gigabit LAN Port.
- 1 x Parallel Port.
- 2 x Serial Ports.
- 8 x USB 2.0/1.1 Ports. (4 integrated, 4 via
optional cables)
- Audio Ports.
|
| RAID |
- 2 x Serial ATA connectors supported by NVIDIA nFORCE 3 250Gb.
(RAID0, 1, 0+1)
- 2 x Serial ATA connectors and 1 x ATA133/RAID IDE Port supported by Promise
PDC20579. (RAID0, 1, 0+1) (For SL-K8AN2E-GR only)
|
| IEEE1394 |
|
| Audio |
6-Channel AC'97 Audio. |
| LAN |
Gigabit 10/100/1000 LAN Function. |
| BIOS |
- Award BIOS.
- Flash Memory for easy upgrade.
|
| Form Factor |
ATX Form Factor (220mm x 305mm) |
| Other Features |
- BIOS FSB Setting.
- BIOS Writing Protection.
- BIOS AGP, DIMM, Vcore Voltage Setting.
- SmartDoc. Anti-burning Shield. (optional)
- Soltek H/M Monitor.
- STR Function. (optional)
|
