| Chipset |
VIA KT880 + VT8237. |
| Processor |
AMD Socket 462 on board. |
| Front Side Bus |
400/333/266MHz Front Side Bus. |
| Memory |
- 2 x 184-pin DDR DIMM Sockets.
- Supporting unregistered non-ECC DDR 400/333/266 DRAM up to 2GB.
- Supporting Dual-Channel.
|
| Expansion Slots |
- 1 x AGP 8X/4X Slot.
- 5 x PCI Slots.
|
| On-Board EIDE |
2 x ATA133/100/66 IDE connectors supporting up to 4 IDE devices. |
| On-Board SATA |
2 x Serial ATA connectors supporting 2 Serial ATA HDDs. (by
VT8237) |
| |
|
| Integrated Super I/O |
- 1 x Floppy Port.
- 1 x PS/2 Mouse Port.
- 1 x PS/2 Keyboard Port.
- 1 x LAN Port. (For SL-KT880E-RL only)
- 1 x Parallel Port.
- 2 x Serial Ports. (1 integrated, 1 via optional
cable)
- 8 x USB 2.0/1.1 Ports. (4 integrated, 4 via
optional cables)
- Audio Ports.
|
| RAID |
2 x Serial ATA connectors supported by VT8237. (RAID0,
1) |
| IEEE1394 |
|
| Audio |
6-Channel AC'97 Audio. |
| LAN |
10/100 LAN Function. (For SL-KT880E-RL only) |
| BIOS |
- AMI BIOS.
- Flash Memory for easy upgrade.
|
| Form Factor |
ATX Form Factor (215mm x 305mm) |
| Other Features |
- BIOS FSB Setting.
- BIOS Writing Protection.
- BIOS AGP, DIMM, Vcore Voltage Setting.
- BIOS Multiplier Setting.
- SmartDoc. Anti-burning Shield. (optional)
- RedStorm2 Overclocking Technology. (optional)
- Soltek H/M Monitor.
|
